You bought something for the boat, now make her smile with Nautical Jewelry!

  • Description

10-30VDC, Internal Driver


Features

  • Recommended for boats 25-330' (7-100m)
  • Flush-fit, suitable for transom, hull side, or bottom mounting
  • Interchangeable array with internal driver
  • Full power Dual-color without sacrificing brightness
  • Use Lumi-Switch for color fade, change speed, brightness control, and strobe
  • 27,000 lumens (12,000 fixture lumens)
  • Wide 110° beam angle for the ultimate flood effect
  • Advanced light engine designed with ATRB (Active Thermal Roll-Back)
  • 3 year warranty


Specification

  • Tring Ring (Bezel) Finish/Material: Marine grade aluminum bronze
  • Housing/Finish Material: Marine grade aluminum bronze
  • Lens Material: BK7 Borosilicate
  • Trim Ring (Bezel) Dimensions: 4.72" (120mm) x 0.33" (8.5mm) profile height
  • Cut-Out Dimensions: 3.375" (86mm)
  • Recessed Depth: 7.30" (184mm)
  • Dimensions: 3.46" (88mm) dia x 5.35" (136mm) shaft length w/cable grommet
  • Input Voltage: 10.5-31VDC
  • Power Consumption: 8.8A (12V), 4.4A (24V)
  • Driver: Multi Channel Interchangeable Driver
  • Output Color: Cool White/Blue
  • Luminous Flux: 27,000 lms (12,000 fixture lms)
  • Beam Angle: 110°
  • Max Operating Temperature: Use in ambient temps up to 125dg F (50dgC)
  • Lifetime Hours: 50,000+ hrs
  • Mounting Method: Thru-hull, bonding connection required
  • Install Location: Transom, hull sides, bottom
  • Ingress Protection: IP68
  • Class: III
  • Electrical Protections: ATRB (automatic thermal rollback), surge, APR (auto power control), soft start, reverse polarity, in-rush current, power line noise suppression
  • Certifications & Compliance: CE, ROHS
  • Manufacturer: Lumishore
  • Warranty: 3 Years
